MikroTik RB951Ui-2HnD Wireless Router

The RB951Ui-2HnD is a wireless SOHO AP with a new generation Atheros CPU and more processing power. It has five Ethernet ports, one USB 2.0 port and a high power 2.4GHz 802.11b/g/n wireless AP with antennas built in. It has a 600MHz CPU,128MB of RAM and PoE output function for port #5 – it can power other PoE capable devices with the same voltage as applied to the unit. Maximum load on the port is 500mA.

MikroTik RB951Ui-2HnD Features

• The RB951Ui-2HnD is a wireless SOHO AP with a new generation Atheros CPU and more processing power
• 2.4GHz AP with five Ethernet ports and PoE output on port 5. It has a 600MHz CPU, 128MB RAM and a USB port
• One USB 2.0 port and a high power 2.4GHz 802.11b/g/n wireless AP with antennas built in
• It has a 600MHz CPU,128MB of RAM and PoE output function for port #5 – it can power other PoE capable devices with the same voltage as applied to the unit. Maximum load on the port is 500mA

  Specifications

  Details
  Product code	RB951Ui-2HnD
  Architecture	MIPSBE
  CPU	AR9344
  CPU core count	1
  CPU nominal frequency	600 MHz
  Dimensions	113x138x29mm
  RouterOS license	4
  Operating System	RouterOS
  Size of RAM	128 MB
  Storage size	128 MB
  Storage type	NAND
  MTBF	Approximately 100’000 hours at 25C
  Tested ambient temperature	-20C +60C
  Suggested price	$59.95

  Wireless capabilities

  Details
  Wireless 2.4 GHz Max data rate	300 Mbit/s
  Wireless 2.4 GHz number of chains	2
  Wireless 2.4 GHz standards	802.11b/g/n
  Antenna gain dBi for 2.4 GHz	2.5
  Wireless 2.4 GHz chip model	AR9344
  Wireless 2.4 GHz generation	Wi-Fi 4

  Ethernet

  Details
  10/100 Ethernet ports	5

  Peripherals

  Details
  Number of USB ports	1
  USB Power Reset	Yes
  USB slot type	USB type A
  Max USB current (A)	1

  Powering

  Details
  Number of DC inputs	2 (DC jack, PoE-IN)
  DC jack input Voltage	8-30 V
  Max power consumption	24 W
  Max power consumption without attachments	7 W
  Cooling type	Passive
  PoE in	Passive PoE
  PoE in input Voltage	8-30 V

  PoE-out

  Details
  PoE-out ports	Ether5
  PoE out	Passive PoE
  Max out per port output (input 18-30 V)	500 mA
  Max total out (A)	500 mA

  Wireless specifications

  2.4 GHz	Transmit (dBm)	Receive Sensitivity
  6MBit/s	30	-96
  54MBit/s	25	-80
  MCS0	30	-96
  MCS7	23	-78
